- Number of Channels 01
- Max Output Power @ 12,6 VDC - 1 OHM: 8000W RMS @ 12,6 VDC - 2 OHMS: 5120W RMS
- Signal Noise/Ratio >90dB
- Frequency Response 10Hz - 10KHz (-3dB)
- Input Impedance 22K Ohms
- Protection System Short Output, Short Output in Relation to the GND, Thermal Protection e High/Low Supply
- Minimum Supply Voltage 9VDC
- Maximum Supply Voltage 16VDC
- Idle Consumption 2A
- Musical Maximum Consumption 373,4A
- Sinusoidal Signal Maximum Consumption 746,90A
- Dimensions (WxHxD) 228 x70 x 419mm
- Weight 6.100Kg
FAQ
We always reccomend a big 3 kit for every vehicle, regardless of the system. However, if you plan on running more than 1,500 watts we reccomend a good AGM battery underhood, and then from there more power will need more electrical upgrades depending on power.
