Synergy Audio SYN series are world class amplifiers in Class D Monoblock formats. They feature high end design, engineering and manufacturing. We utilize the best quality components to insure the best possible performance and reliability.
Model | SYN-3.5K | ||||||||||||||||
RMS power @ 4 ohm | 1500 W X 1 | ||||||||||||||||
RMS power @ 2 ohm | 2600 W X 1 | ||||||||||||||||
RMS power @ 1 ohm | 3500 W X 1 | ||||||||||||||||
RMS power @ 4 ohm mono | |||||||||||||||||
Amplifier Type | Class D | ||||||||||||||||
Minimum load impedance | 1 ohm stable | ||||||||||||||||
Input Sensitivity | 0.2 V - 6 V | ||||||||||||||||
Low Pass Filter | 35 Hz - 250 Hz | ||||||||||||||||
Subsonic Filte | 10 Hz - 50 Hz | ||||||||||||||||
Frequency Response | 10 Hz - 250 Hz | ||||||||||||||||
Signal to Noise Ratio | 85 dB | ||||||||||||||||
THD@4ohm | 50.1% | ||||||||||||||||
Damping Factor | >200 | ||||||||||||||||
Working voltage | 9V-16V | ||||||||||||||||
Fuse Rating | 150 Ax 2 | ||||||||||||||||
Dimensions ( L inches ) | 19.69 | ||||||||||||||||
9.45 W x 2.44 H inches |
Model | SYN-3.5K | ||||||||||||||||
RMS power @ 4 ohm | 1500 W X 1 | ||||||||||||||||
RMS power @ 2 ohm | 2600 W X 1 | ||||||||||||||||
RMS power @ 1 ohm | 3500 W X 1 | ||||||||||||||||
RMS power @ 4 ohm mono | |||||||||||||||||
Amplifier Type | Class D | ||||||||||||||||
Minimum load impedance | 1 ohm stable | ||||||||||||||||
Input Sensitivity | 0.2 V - 6 V | ||||||||||||||||
High Pass Filter Low Pass Filter |
35 Hz - 250 Hz | ||||||||||||||||
Subsonic Filte | 10 Hz - 50 Hz | ||||||||||||||||
Bass Boost Frequency Response |
10 Hz - 250 Hz | ||||||||||||||||
Signal to Noise Ratio | 85 dB | ||||||||||||||||
THD@4ohm | 50.1% | ||||||||||||||||
Damping Factor | >200 | ||||||||||||||||
Working voltage | 9V-16V | ||||||||||||||||
Fuse Rating | 150 Ax 2 | ||||||||||||||||
Dimensions ( L inches ) | 19.69 | ||||||||||||||||
9.45 W x 2.44 H inches |
