PRO-FR69 NEO | 6x9" 250 WATT RMS FULL-RANGE LOUDSPEAKER
Lease for as low as $/week
Guaranteed safe & secure checkout
Versatility is paramount in large and small audio systems alike. Many DS18 fans have been wanting a more powerful 6x9 so they can get clear and loud sound from their 6x9s. We have obliged the overwhelming requests by releasing our PRO-FR69NEO. This Neodymium driven midrange speaker will be the loudest 6x9 we have while also handling the most power. The great thing about NEO motor structures is that you get better performance, higher wattage handing, better efficiency, and much lighter in weight than a traditional speaker with a ferrite motor structure. This is a 4 ohm speaker that handles 250w RMS and 500e MAX power with a DB sensitivity rating of 98db. This neo also has a built in bullet resonator to help this screaming mids range all the way from 100hz to 9000hz with extreme clarity and loudness.
Key Features:
- Neodymium motor structure that handles more power, lighter, and more efficient than ferrite motors.
- Silver bullet resonator that will bring the loudness and clarity of this speaker to the highest pinnacle.
- High RMS rating of 250w RMS and 500w MAX @4 ohms so you can have a very high powered 6x9 to blow away the competition.
- High decibel rating so it does not take max power to get the fullest sound.
Specifications:
| Nominal Diameter | 6x9" |
| Nominal Impedance | 4 ohms |
| RMS Power Handling | 250w |
| MAX Power Handling | 500w |
| Sensitivity (1w/1m) | 98dB |
| Frequency Response | 100Hz-9KHz |
| Recommended HI Pass Crossover | 120Hz |
| MOTOR | |
| Voice Coil Diameter | 38.6mm/1.5" |
| Voice Coil Former Material | Kapton |
| Winding Material | CCAW |
| Cone Material | Paper |
| Bullet Material | Aluminum |
| Surround Material | Cloth |
| Basket Material | Aluminum |
| Magnet Material | Neodymium |
| Magnet Weight | 2.8Oz |
| Displacement Volume | 0.0524L |
| MEASUREMENTS | |
| Overall Diameter | 9.44X6.57" |
| Overall Depth | 3.31" |
| Front Mount Baffle Cutout | 8.74X5.97" |
| Mounting Depth | 2.874" |
| Motor Diameter | 4.13" |
MANUAL
FAQ
We always reccomend a big 3 kit for every vehicle, regardless of the system. However, if you plan on running more than 1,500 watts we reccomend a good AGM battery underhood, and then from there more power will need more electrical upgrades depending on power.
